Silicone Rubber Wire Seal 1394133-1
Part NO.:1394133-1
Cavity Diameter:4.0mm
Accepts Cable Diameter Range:1.0mm
Length of Seal:8.0mm
- Product Introduction
Product Parameters
| Product | silicone rubber wire seal 1394133-1 |
| Part NO. | 1394133-1 |
| Seal Material | Silicone |
| Color | Blue |
| Connector Seal Type | Single Wire Seal(SWS) |
| Cavity Diameter | 4.0mm |
| Accepts Cable Diameter Range | 1.0mm |
| Length of Seal | 8.0mm |
Features:
Material:Silicone
Installation Style:Cable Mount / Free Hanging
Sealed/Unsealed:Sealed
MOQ:We can accept small quantity if we have stock.Small order will be allowed.
Packing Method:100/200/300/500/1000 per bag with label,export standard carton,or according to client’s requirements.
Sample:Free of charge.1 to 3 pieces for each item you require.
Service:OEM/ODM,customization as per clients requirements.
Market:35% North America,25% Europe,15% Asia,10% Mid East,15% other area.
Package & Shipment:
Package:
We usually use strong poly bag to pack silicone rubber wire seal 1394133-1,100/200/300/500/1000 per bag with label,export standard carton,or according to client’s requirements.Terminals in roll package or bulk packing.Seals will be packed into poly bag as well,the quantity as per the dimention of seals.
Note：
Interface from seal to contact
Without leaving surface wounds, the contact barrels shut and hold the silicone rubber wire seal 1394133-1. The assembling process is completely automated.
Sealing interface with cavity
The cavity is then sealed with the seal that was crimped onto the contact. A radial compression of the rubber element and the ensuing sealing pressure at the interface are caused by the discrepancy between the outer diameter of the seal and the cavity diameter. As a result of this interference, the wire interface experiences more closure pressure, tightening up toward the cable.
